Portable IR thermal body temperature monitoring System
BIOS02 -Handheld or tripod mounted visual IR thermal body temperature monitoring & alerting syste
The BIOS02 portable handheld infrared thermal body thermal camera that has been specially calibrated for measuring body temperature. The unit supports a built-in battery that allows it to be operated both outdoors as well as indoors. The unit can be operated as handheld or mounted on a tripod to monitor/scan a person for high body temperature. The device can be quickly deployed in areas where it is not possible to connect to power outlets. The unit can take temperature scans of people at 3 feet distance with an accuracy of +-5C (.9F) as they walk past the unit. The unit generates alerts whenever it detects elevated body temperatures.
Key features
2.8" TFT Screen
Temperature range: 30C to 40C
Precision: +- .5C (0.9F) over 3 feet
Portable handheld or can be mounted on tripod
USB interface to PC for alerting & monitoring software
IP65 waterproof rating for outdoor operation
Use cases
1. The unit can operate in a handheld mode for scanning people in crowded places such as outdoor event venues or in malls. This can be used in addition to typical long-range IR camera monitoring and surveillance systems for more accurate closer range reading.
2. Airports for scanning users as they file through security lines
3. Hospital entrances to detect patients with high temperature and isolate them to a safer place
4. In schools to monitor students as they file through entrances
5.. By bus drivers to scan passengers as they onboard the bus
Specifications
Infrared resolution: 160 x120
frame frequency: 9 Hz
Temperature range: 30℃~45℃
Precision: ±0.5℃ (0.9F)
SD card: Support
Battery: 3.7V / 5000mAh
Product size: 236x75.5x86 mm
Compatible with: Type-C USB
Resolution: 640 * 480
Protection class: IP65
Key Features
Caliberated for body temperature reading
Easy to deploy and operate
Portable and handheld
Range upto 3 feet with +-0.5C (0.9F)
Real-time mode for viewing the images on a PC or monitor and alerting on high temperature
Pricing starts at $1250 for the unit with application managment sotware + tripod. PC not included.
Note:
This unit is not a medical FDA approved thermometer. It is to be be used for initial fast screening of people for elevated body temperatures.
Body temperature measurement from this device should not be solely or primarily relied upon to diagnose or exclude a diagnosis of a disease.
Elevated body temperature as detected by this device must be confirmed with a secondary NCIT or FDA approved clinical grade contact thermometer.
Implementation Use Cases
The unit can be operated as a handheld for scanning targetted people in a crowd at a close range. For example, in places where it is not possible to have a PC monitoring station, this unit can be used by security personnel to screen individual users,
Mounted on a tripod it can be connected to a PC for fast real-time screening .
